Multi-Tenant Solutions
Enterprise class communication solutions to provide multi-tenant or campus wide AV-over-IP integration capabilities.
24 Port Client side managed Gigabit Layer 3 PoE Networking switch. Ideal for larger MDU VLAN Installations.
36 Port Gigabit Layer 3 Fiber Convergence Networking switch. Ideal for larger MDU VLAN Installations.
8 Port Client side managed Gigabit Layer 3 PoE Networking switch. Ideal for MDU VLAN Installations.
The ideal communication mediator and the most popular for single residence installations or small to medium size multi-dwelling units (MDU) for 20 devices plus.
The AVLinkPro 360RAD is a Enterprise communication bridge that allows for medium and large installations such as Multiple Unit Dwellings and campuses. It Features expansion to High Availability applications for unmatched redundant operation.
The LP-360-X model delivers all the benefits of the LP360 series with the additional added features of a full surveillance solution as well as Network Video Recording.
The LP360 series with V-Sense offers the power of a totally touch-less intercom enhancement. A full featured Communication bridge with visual human face triggers.
The AVLinkPro Radius is a Enterprise communication bridge that allows for medium and large installations such as Multiple Unit Dwellings and campuses.
AVLinkPro Layer 3 Managed 24 Port POE switch (CLIO-24 )
Introducing the AVLinkPro CLIO Series advanced network switch. CLIO switches can provide WEB/CLI managed modes, SNMP, bringing abundant management features to your next integration. A new series of managed PoE switches that automatically detect PoE requirements. This includes 48V, 24V, Passive or Active PoE allowing you to power many different devices without the need for additional PoE adapters & injectors.
- 24x 1000Mbps Gigabit PoE Ports (48V / 24V Adaptable)
- 2x 1000Mbps Gigabit SFP Ports
- 400W Power Budget (30W per Port)
- Managed Switch with L2/L3/L3 , QoS & IGMP Security
24 Port Client side managed Gigabit Layer 3 PoE Networking switch. Ideal for larger MDU VLAN Installations.
AvlinkPro Layer 3 Managed 36 Port SFP combo Switch with 4 SFP 10G uplink ports (CLIO36SFP )
Introducing the AVLinkPro CLIO Series advanced network switch. CLIO switches can provide WEB/CLI managed modes, SNMP, bringing abundant management features to your next integration. A new series of managed Layer 3 switches that work in unison.
IEEE 802.3
IEEE 802.3u 100BASE-TX
IEEE 802.3ab1000BASE-T
IEEE 802.3x
IEEE 802.3z 1000BASE-X
IEEE 802.3ad, IEEE 802.ae
IEEE 802.3q 、IEEE 802.3q/p
IEEE 802.1w、IEEE 802.1d 、IEEE 802.1S
STP(Spanning Tree Protocol)
RSTP/MSTP( Rapid Spanning Tree Protocol)
- 8x 1000Mbps Gigabit PoE Ports (48V / 24V Adaptable)
- 24x 1000Mbps Gigabit SFP Ports
- 4 x 100M/1000M/10000M SFP
- Managed Switch with L2/L3/L3 , QoS & IGMP Security
IEEE 802.3
IEEE 802.3u 100BASE-TX
IEEE 802.3ab1000BASE-T
IEEE 802.3x
IEEE 802.3z 1000BASE-X
IEEE 802.3ad, IEEE 802.ae
IEEE 802.3q 、IEEE 802.3q/p
IEEE 802.1w、IEEE 802.1d 、IEEE 802.1S
STP(Spanning Tree Protocol)
RSTP/MSTP( Rapid Spanning Tree Protocol)
36 Port Gigabit Layer 3 Fiber Convergence Networking switch. Ideal for larger MDU VLAN Installations.
AVLinkPro Layer 3 Managed 8 Port POE with 2 1G SFP port switch (CLIO-8 )
Introducing the AVLinkPro CLIO Series advanced network switch. CLIO switches can provide WEB/CLI managed modes, SNMP, bringing abundant management features to your next integration. A new series of managed PoE switches that automatically detect PoE requirements. This includes 48V, 24V, Passive or Active PoE allowing you to power many different devices without the need for additional PoE adapters & injectors.
- 8x 1000Mbps Gigabit PoE Ports (48V / 24V Adaptable)
- 2x 1000Mbps Gigabit SFP Ports
- 150W Power Budget (30W per Port)
- Managed Switch with L2/L3/L3 , QoS & IGMP Security
8 Port Client side managed Gigabit Layer 3 PoE Networking switch. Ideal for MDU VLAN Installations.
AVLinkPro LP-360 /LP-400 1U Rack Capable SIP PBX (LP-360RMB/LP-400)
Crestron Intercom 1U Pro AV Rack Mountable SIP Bridge Controller, ideal integration device for managed connectivity to most IP based video doorbell intercoms and door lock relays. Engineered for enhanced residential, commercial or multi-tenant Intercom applications. Ideal for any Crestron eco-system to enhance building communications and connectivity.
Crestron Intercom 1U Pro AV Rack Mountable SIP Bridge Controller, ideal integration device for managed connectivity to most IP based video doorbell intercoms and door lock relays. Engineered for enhanced residential, commercial or multi-tenant Intercom applications. Ideal for any Crestron eco-system to enhance building communications and connectivity.
- Designed to manage 1-20 Plus SIP Endpoints
- Compact 1U Height Size (4.29″ x 5.07″ x1.33″)
- Configure through web interface
- Provides Video Connectivity through H.323 SIP
- Full featured Intercom PBX Functions
- Early video from intercom calls
- Unicast video to multiple devices
- Audio Voicemail
- Audio / Video Paging
- Touch Screen Panel to Panel Communication
- Crestron Certified Partner Product
- Crestron Advanced Auto-Discovery for touch panels
- Built in Single Throw Double Pole Relay
- Intelligent Audio Attendant
- Advanced Crestron Discovery
- New – Interface API
- Enhanced VLAN capability
- Crestron HOME SIPAHOY Platform option included
- Supports XBABBLE Mobile Communications
- Analog Audio Output
- AES67 2 Channel Audio output
- 2 x LAN 10/100/1000 LAN Ports
- 180 Watt Power Supply
- Includes Rack Ears
The ideal communication mediator and the most popular for single residence installations or small to medium size multi-dwelling units (MDU) for 20 devices plus.
AVLinkPro LP-360RAD 1.3U Redundant Enterprise (LP-360RAD)
A fully redundant MDU SIP Bridge designed for flexibility in large scale installations.
The AVLinkPro LP360RAD is a SIP/RTSP/TCP/IP Enterprise connecting bridge that allows for medium and large enterprise installations to have full connectivity and adequate expansion. Multiple Unit Dwellings and Campus wide installations can take advantage of video intercom, SIP connected communications, Cross platform control and seamless integration.
- 1.3U Height Rack Chassis
- Intel® Core Quad Core 2.80GHz Processor
- Redundant 120GB Solid State Data Storage
- Web Based Configuration
- Provides Video Connectivity
- Provides Audio Connectivity
- Simple PBX Functions
- Voicemail with Video
- Audio / Video Paging
- Transcoding Video Stream
- Programmable Trigger Output
- Includes 50 SIP Channels (Expandable to 1000)
- Designed to Handle Large Scale Connections
- Touch Screen Panel to IP Video Bridge
- Can Bridge Telephony Systems
- 2 x Expandable IO Slots
- 2 x LAN 10/100/1000 LAN Ports (VLAN Support)
- 5.1 Channel Audio
- AES67 IP Interoperability Audio Support
- 1 x HDMI Configurable ports
- 1 x GBIC
- Onboard PCIE
- Redundant Power Supplies
- RAID 1 Hot Swap SSD drives
- High Availability ready when paired with a second LP360RAD
Additional SIP Channel add-on licenses available
The AVLinkPro 360RAD is a Enterprise communication bridge that allows for medium and large installations such as Multiple Unit Dwellings and campuses. It Features expansion to High Availability applications for unmatched redundant operation.
AVLinkPro LP-360RM_X 1U Surveillance System (LP-360RMB_X)
Crestron Intercom 1U Pro AV Rack Mountable SIP Bridge Controller with V-Sense and Surviellance plus NVR, ideal integration device for managed connectivity to most IP based video doorbell intercoms and door lock relays. Engineered for enhanced residential, commercial or multi-tenant Intercom applications. Ideal for any Crestron eco-system to enhance building communications and connectivity.
Crestron Intercom 1U Pro AV Rack Mountable SIP Bridge Controller with V-Sense and Surviellance plus NVR, ideal integration device for managed connectivity to most IP based video doorbell intercoms and door lock relays. Engineered for enhanced residential, commercial or multi-tenant Intercom applications. Ideal for any Crestron eco-system to enhance building communications and connectivity.
- Enhanced Processor
- 2TB SSD NVR Storage
- Manages Onvif/RTSP Video Sources
- Designed to manage 1-20 Plus SIP Endpoints
- Compact 1U Height Size (4.29″ x 5.07″ x1.33″)
- Configure through web interface
- Provides Video Connectivity through H.323 SIP
- Full featured Intercom PBX Functions
- Early video from intercom calls
- Unicast video to multiple devices
- Audio Voicemail
- Audio / Video Paging
- Touch Screen Panel to Panel Communication
- Crestron Certified Partner Product
- Crestron Advanced Auto-Discovery for touch panels
- Built in Single Throw Double Pole Relay
- Intelligent Audio Attendant
- Advanced Crestron Discovery
- New – Interface API
- Enhanced VLAN capability
- ZoneMinder Surveillance System
- V-Sense detection enabled
- Crestron HOME SIPAHOY Extension capable
- Supports XBABBLE Mobile Communications
- Analog Audio Output
- AES67 2 Channel Audio output
- 2 x LAN 10/100/1000 LAN Ports
- 180 Watt Power Supply
- Includes Rack Ears
The LP-360-X model delivers all the benefits of the LP360 series with the additional added features of a full surveillance solution as well as Network Video Recording.
AVLinkPro LP-360_V 1U VSense Recognition (LP-360RMB_V)
Crestron Intercom 1U Pro AV Rack Mountable SIP Bridge Controller with VSense human visual trigger detection, ideal integration device for managed connectivity to most IP based video doorbell intercoms and door lock relays. Engineered for enhanced residential, commercial or multi-tenant Intercom applications. Ideal for any Crestron eco-system to enhance building communications and connectivity.
- Designed to manage 1-20 Plus SIP Endpoints
- Compact 1U Height Size (4.29″ x 5.07″ x1.33″)
- Configure through web interface
- Provides Video Connectivity through H.323 SIP
- Full featured Intercom PBX Functions
- Early video from intercom calls
- Unicast video to multiple devices
- Audio Voicemail
- Audio / Video Paging
- Touch Screen Panel to Panel Communication
- Crestron Certified Partner Product
- Crestron Advanced Auto-Discovery for touch panels
- Built in Single Throw Double Pole Relay
- Intelligent Audio Attendant
- Advanced Crestron Discovery
- V-Sense Enabled
- New – Interface API
- Enhanced VLAN capability
- Crestron HOME SIPAHOY Extension capable
- Analog Audio Output
- AES67 2 Channel Audio output
- 2 x LAN 10/100/1000 LAN Ports
- 180 Watt Power Supply
- Includes Rack Ears
The LP360 series with V-Sense offers the power of a totally touch-less intercom enhancement. A full featured Communication bridge with visual human face triggers.
AVLinkPro LP-RADPRO 3U Redundant Enterprise (LP-RADPRO)
A full featured MDU SIP Bridge designed for flexibility in large scale installations.
The AVLinkPro Radius is a SIP/RTSP/TCP/IP Enterprise connecting bridge that allows for medium and large enterprise installations to have full connectivity and adequate expansion. Multiple Unit Dwellings and Campus wide installations can take advantage of video intercom, SIP connected communications, Cross platform control and seamless integration.
- 2U Height Rack Chassis
- Intel® Core i5 Quad Core 2.80GHz Processor
- Redundant 120GB Solid State Data Storage
- Web Based Configuration
- Provides Video Connectivity
- Provides Audio Connectivity
- Simple PBX Functions
- Voicemail with Video
- Audio / Video Paging
- Transcoding Video Stream
- Programmable Trigger Output
- Includes 50 SIP Channels *
- Designed to Handle Large Scale Connections
- Designed for the SIPAHOY Enterprise platform
- Supports XBABBLE Mobile Communications
- Touch Screen Panel to IP Video Bridge
- Can Bridge Telephony Systems
- 2 x Expandable IO Slots
- 2 x LAN 10/100/1000 LAN Ports (VLAN Support)
- 5.1 Channel Audio
- AES67 IP Interoperability Audio Support
- 2 x HDMI Configurable ports
- 1 x RS-232 Port
- 1 x RS232/422/485
- 460 Watt Redundant Power Supply
- Rail Kit Included
* SIP Channel add-on licenses available
The AVLinkPro Radius is a Enterprise communication bridge that allows for medium and large installations such as Multiple Unit Dwellings and campuses.
